ASUS GeForce RTX 3070 Noctua Edition (LHR), RTX3070-8G-NOCTUA, 8GB GDDR6, 2x HDMI, 3x DP
- Modell
- NVIDIA GeForce RTX 3070
- Speicher
- 8GB GDDR6, 256bit, 14Gbps, 1750MHz, 448GB/s
- Takt Basis
- 1500MHz (Standard-Profil), 1500MHz (OC-Profil)
- Takt Boost
- 1725MHz (Standard-Profil), 1755MHz (OC-Profil)
- Übertaktung
- +30MHz Boost (OC-Profil)
- Kühlung
- 2x Axial-Lüfter (120mm, Noctua NF-A12x25 PWM) mit 0dB-Zero-Fan-Modus (bis 50°C)
- TDP/TGP
- 220W (NVIDIA)
- Stromanschlüsse
- 2x 8-Pin PCIe
- Anschlüsse
- 2x HDMI 2.1, 3x DisplayPort 1.4a
- Anbindung
- PCIe 4.0 x16
- Besonderheiten
- mit LHR (Lite Hash Rate), Backplate, AI-Beschleunigung, Taktprofile (Default Mode/OC Mode)
- Gesamthöhe
- Penta Slot (4.3 Slots)
Bitte ggf. die Filterkriterien ändern.
Weitere Varianten (Top-10)
ASUS TUF Gaming GeForce RTX 3070 OC, TUF-RTX3070-O8G-GAMING, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FQ6-M0NA00ASUS ROG Strix GeForce RTX 3070 OC V2 (LHR), ROG-STRIX-RTX3070-O8G-V2-GAMING, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FR7-M0NA00ASUS TUF Gaming GeForce RTX 3070 OC V2 (LHR), TUF-RTX3070-O8G-V2-GAMING, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FQI-M0NA00ASUS Dual GeForce RTX 3070 OC, DUAL-RTX3070-O8G, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FQ0-M0NA00ASUS Dual GeForce RTX 3070 SI, DUAL-RTX3070-8G-SI, 8GB GDDR6, HDMI, 3x DP
90YV0H60-M0NB00ASUS GeForce RTX 3070 Noctua OC Edition (LHR), RTX3070-O8G-NOCTUA, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FQQ-M0NA00ASUS ROG Strix GeForce RTX 3070 V2 White (LHR), ROG-STRIX-RTX3070-8G-WHITE-V2, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FRA-M0NA00ASUS ROG Strix GeForce RTX 3070 OC White V2 (LHR), ROG-STRIX-RTX3070-O8G-WHITE-V2, 8GB GDDR6, 2x HDMI, 3x DP
90YV0FR9-M0NA00ASUS Turbo GeForce RTX 3070 V2 (LHR), TURBO-RTX3070-8G-V2, 8GB GDDR6, HDMI, 3x DP
90YV0FP3-M0NB00Ähnliche Produkte (Top-10 in PCIe)
ASUS ROG Astral GeForce RTX 5090 OC, ROG-ASTRAL-RTX5090-O32G-GAMING, 32GB GDDR7, 2x HDMI, 3x DP
90YV0LW0-M0NA00ASUS Prime Radeon RX 9070 XT OC, PRIME-RX9070XT-O16G, 16GB GDDR6, HDMI, 3x DP
90YV0L71-M0NA00ASUS Dual GeForce RTX 5060 Ti OC, DUAL-RTX5060TI-O16G, 16GB GDDR7, HDMI, 3x DP
90YV0MH0-M0NA00GIGABYTE Radeon RX 9070 XT Gaming OC 16G, 16GB GDDR6, 2x HDMI, 2x DP
GV-R9070XTGAMING OC-16GDASRock Radeon RX 9070 Challenger 16GB, RX9070 CL 16G, 16GB GDDR6, HDMI, 3x DP
90-GA5NZZ-00UANFGIGABYTE Radeon AI PRO R9700 AI TOP 32G, 32GB GDDR6, HDMI, 3x DP
GV-R9700AI TOP-32GDASUS Dual Radeon RX 9060 XT, DUAL-RX9060XT-16G, 16GB GDDR6, HDMI, 2x DP
90YV0LG2-M0NA00 / 90YV0LG2-M0AA00XFX Swift Radeon RX 9070 XT Triple Fan Gaming Edition, 16GB GDDR6, HDMI, 3x DP
RX-97TSWF3B9ASUS Prime GeForce RTX 5070 Ti OC, PRIME-RTX5070TI-O16G, 16GB GDDR7, HDMI, 3x DP
90YV0MF0-M0NA00ASUS Prime Radeon RX 9070 XT White OC Edition, PRIME-RX9070XT-O16G-WHITE, 16GB GDDR6, HDMI, 3x DP
90YV0L75-M0NA00- Modell
- NVIDIA GeForce RTX 3070
- Speicher
- 8GB GDDR6, 256bit, 14Gbps, 1750MHz, 448GB/s
- Takt Basis
- 1500MHz (Standard-Profil), 1500MHz (OC-Profil)
- Takt Boost
- 1725MHz (Standard-Profil), 1755MHz (OC-Profil)
- Übertaktung
- +30MHz Boost (OC-Profil)
- Kühlung
- 2x Axial-Lüfter (120mm, Noctua NF-A12x25 PWM) mit 0dB-Zero-Fan-Modus (bis 50°C)
- TDP/TGP
- 220W (NVIDIA)
- Stromanschlüsse
- 2x 8-Pin PCIe
- Anschlüsse
- 2x HDMI 2.1, 3x DisplayPort 1.4a
- Anbindung
- PCIe 4.0 x16
- Besonderheiten
- mit LHR (Lite Hash Rate), Backplate, AI-Beschleunigung, Taktprofile (Default Mode/OC Mode)
- Gesamthöhe
- Penta Slot (4.3 Slots)
- Abmessungen
- 310x147x87.5mm (LxBxH)
- Bauform
- PCIe-Karte (full height)
- Slotblende
- full height
- AI-Rechenleistung (dense)
- 163 TOPS (FP16)
- AI-Rechenleistung (sparse)
- 326 TOPS (FP16)
- GPU-Rechenleistung
- 21.20 TFLOPS (FP16), 21.20 TFLOPS (FP32), 0.33 TFLOPS (FP64)
- Chip-Daten
- Chip-Architektur
- NVIDIA Ampere (ab 2020/Q3)
- Chip-Bezeichnung
- GA104 (GA104-300-A1)
- Chip-Ausbau
- 95.8% aktive Recheneinheiten (46/48 SM)
- Chip-Konfiguration
- 46SM (5888SP/184TMU/96ROP), 46 RT-Cores, 184 Tensor-Cores, 4MiB L2-Cache
- Chip-Fertigung
- Samsung 8nm (8nm)
- Chip-Größe
- 392mm², monolithisch, 17.4 Mrd. Transistoren
- Chip-Funktionen
- Raytracing (2nd Gen NVIDIA RTX), NVIDIA Tensor (3rd Gen, 163 TOPS), HDCP 2.3
- Chip-Verwendung
- GeForce RTX 3070 Ti
GeForce RTX 3070
GeForce RTX 3060 Ti
GeForce RTX 3060
RTX A4000 - API-Unterstützung
- DirectX 12 Ultimate (12_2) / CUDA 8.6 / Vulkan 1.3 / OpenCL 3.0 / OpenGL 4.6 / Shader Model 6.7
- Transcoding-Engine
- 1x NVENC (7th Gen, max. Sessions: 8), 1x NVDEC (5th Gen), Info
- Encoding
- H.265 (4K YUV 4:2:0 / 4K YUV 4:4:4 / 4K Lossless / 8K / HEVC 10bit support / HEVC B Frame support), H.264 (YUV 4:2:0 / YUV 4:4:4 / Lossless)
- Decoding
- AV1 (8bit / 10bit), H.265 (8bit 4:2:0 / 10bit 4:2:0 / 12bit 4:2:0 / 8bit 4:4:4 / 10bit 4:4:4 / 12bit 4:4:4), H.264 (8bit 4:2:0), VP9 (8bit / 10bit / 12bit), VP8, VC-1, MPEG-2, MPEG-1
- Multi-GPU-Anbindung
- -
- Veröffentlichung (Serie)
- 01.09.2020, Verkaufsstart: 29.10.2020, UVP: 499 USD (NVIDIA)
- Grafik
- NVIDIA GeForce RTX 3070 - 8GB GDDR6 - Desktop (LHR)
- Segment
- Consumer
- Letztes Preisupdate
- -
- Gelistet seit
- 2021-10-04, 16:40
-
3dcenter.org: Launch-Analyse nVidia GeForce RTX 3070
-
pcgameshardware.de: Geforce RTX 3070 8 GB im Test: Spezial-Benchmarks visualisieren Speichermangel
-
computerbase.de: Nvidia Ampere RTX-3000-Technik im Detail
-
nvidia.com: GeForce RTX 3070 Family
-
techpowerup.com: NVIDIA GeForce Ampere Architecture, Board Design, Gaming Tech & Software
Bewertung für ASUS GeForce RTX 3070 Noctua Edition (LHR), RTX3070-8G-NOCTUA, 8GB GDDR6, 2x HDMI, 3x DP
Teilen Sie uns Ihre Meinung zu ASUS GeForce RTX 3070 Noctua Edition (LHR), RTX3070-8G-NOCTUA, 8GB GDDR6, 2x HDMI, 3x DP mit oder lesen Sie die Bewertungen unserer Mitglieder, Experten und anderer Websites zu dessen Varianten.-
hardwareluxx.de: ASUS GeForce RTX 3070 Noctua Edition im Test
Die Vorstellung der ASUS GeForce RTX 3070 Noctua Edition sorgte für einiges Aufsehen, denn schließlich hat sich Noctua bei Lüftern und Kühlern einen gewissen Namen erarbeitet, der nun in einer Zusammenarbeit mit ASUS in der Kühlung einer Grafikkarte aufgehen soll. Wie gut dies gelungen ist und wo hier auch zukünftig Chancen zu suchen sind, schauen wir uns im folgenden Test an.
-
-
guru3d.com: ASUS GeForce RTX 3070 Noctua OC review (translate)
High-end graphics cards follow a formula that's been tried and implemented over and over again, look at the STRIX series which have been an ongoing success with very few changes. Choosing a vendor these days; you do base on aesthetics, cooling performance, and, in 2021, availability, as performance for most cards is essentially the same. With that in mind, I seem to appreciate more and more what ASUS tried to accomplish with the Noctua Edition RTX 3070, it's something else, a different approach, and we like that. It really is one of the quietest high-end graphics cards on the market, however at the cost of a massive 4.3-slot form factor paired with two high-quality but brown/beige fans. The end result is a virtually silent product in its default configuration. The exceptionally low noise levels allow this product to be a notch more expensive. The RTX 3070 Noctua OC originally had an MSRP of $830, that however already is a $330 premium over the NVIDIA-specified MSRP of $500. Pricing and actual availability will remain to be the biggest hurdle, we looked and found this product selling for 1250 EUR, and that's just a massive no-go zone. The acoustic and temperature performance both are grand, the looks however trivial, the performance is as expected. Overall, if you think from an audiophile point of view, the product has a lot of merits. But again, there are lots of premium products out there that perform close in acoustics with looks to match. Perhaps in the future next to the DUAL, TUF, and STRIX lines we'll see other cards based on an ASUS Noctua line, devoted to those demanding extremely low noise operation. And this conclusion needs to end there. The release of the Noctua 3070 is more of a trial than something for the masses. The release creates a bit of marketing hype and if you're lucky you'll find one in etail. However future designs and gauging the interest of the public with a Noctua series is what this release likely is all about. Recommended for those interested in true silent operation.
-
techpowerup.com: ASUS GeForce RTX 3070 Noctua OC Review (translate)
The ASUS GeForce RTX 3070 Noctua OC is a pleasant surprise this season, which is dominated by news from AMD and Intel. Personally, I've always wondered why Noctua doesn't get involved in more collaborations—with an extremely strong reputation and brand name, they are THE cooling specialists. I feel like ASUS is a great match for Noctua, as they have tons of experience with graphics card engineering and can offer the resources to support such a project.
